HDI PCB Manufacturer
HDI PCB stands for High-Density Interconnect Printed Circuit Board. It is a type of printed circuit board (PCB) that is designed to have a higher component density than traditional PCBs, allowing for smaller and more complex electronic devices. HDI PCBs are manufactured using advanced techniques such as laser drilling and microvias, which allow for smaller interconnections and higher circuit densities.
HDI PCB Manufacturing Solutions
In the PCB design world, HDI PCB Technology refers to High-Density Interconnect PCB. High Density Interconnect PCB is a printed circuit board with a comparatively higher wiring density per unit area when compared with a conventional board.HDI PCBs have a number of advantages over traditional PCBs, including,allowing for smaller and more complex electronic devices. HDI PCBs are manufactured using advanced techniques such as laser drilling and microvias, which allow for smaller interconnections and higher circuit densities.
We can provide to...
- Turn times as short as 24 hours
- 1 to 100,000 units
- Class II Inspection standard and Class III Inspection available
- 100% on-time guarantee
- DFM support
- Lead free (RoHS) options
- SMT and thru-hole capabilities
- All SMT machine placed
- AOI (Automated Optical Inspection)
- Lead-free RoHS Certification and ITAR compliance screen available
-
Program Design
-
flex Board Capability
-
PCB manufacturing Capabilities
-
Equipment Exhibition
From component purchasing to function test and package finish , we provide one shop stop services for every types of PCB.
Quick payment
Flexible payment options
On-Demand Manufacturing
No MOQ or MPQ limited. Prototype or mass production order acceptable.
Inspection Of Quality
90% of the technical staff have more than 10 years of industry experience
flex Board Capability
| Layer Count | 1-6L 1-4 L normal |
| Board Thickness | 0.1-0.5mm (1-4L) 0.6-0.8mm (5-6L) |
| The tolerance of 1L board thickness | ±0.03mm |
| The tolerance of 2L board thickness | ±0.03mm |
| The tolerance of multilayer board thickness | ±10% (Normal ±0.1mm） |
| The tolerance of multilayer board thickness | ±10% (Normal ±0.05mm） |
| The tolerance of board thickness | ±10% (Normal ±0.1mm） |
| The tolerance of board thickness | 9inch*23inch（PI≥1mil） 9inch*14inch (normal) |
| Max finished board size | 2mm*4mm（no connection tab）；8mm*8mm（with connection tab） |
| Min finished board size | 生益 SF305： PI=0.5mil， 1mil， 2mil； Cu=0.33OZ， 0.5OZ， 1OZ |
| Adhesive flex core | 杜邦AP：PI=1mil，2mil，3mil,4mil；Cu=0.5oz，1oz, 2oz |
| Adhesiveless core | 杜邦AP：PI=1mil，2mil，3mil,4mil；Cu=0.5oz，1oz, 2oz |
| Thermosetting adhesive | 杜邦LF：0110,0210 |
| PI stiffener | 台虹 MHK 系列： PI=3mil， 5mil ， 7mil， 9mil |
| 3M tape | 9077,9460 |
| Finished copper thickness 12um / 18um | 3/3mil |
| Finished copper thickness 35um | 4/3.5mil |
| Finished copper thickness 70um | 6/5mil |
| Solder mask bridge min. (copper thickness<=1oz) | 4mil(Green)，5mil(White)，8.0mil（big copper area） |
| Solder mask opening (single side) | 6mil，8mil（big copper area） |
| Solder mask opening of NPTH (single side) | 3mil(partial2.5mil) |
| Min. coverlay bridge | 8mil |
| Finished copper thickness 12um / 18um | 5/5mil (after compensation) |
| Finished copper thickness 35um | 6.5/5mil (after compensation) |
| Finished copper thickness 70um | 10/8mil (after compensation) |
| Min. Inner layer annual ring width | 4mil（＜4L），7mil（4-6L），9mil（7-8L） |
| The min distance between inner layer isolated pad and copper area | 3.5mil 4mil normal |
| Max finished inner layer copper thickness | 3oz 2 oz normal |
| Finished copper thickness, before compensation | 3/3mil |
| Finished copper thickness 35um, before compensation | 3.5/3.5mil |
| Finished copper thickness 70um, before compensation | 5.5/5mil |
| Finished copper thickness 35um, | 3mil（＜2mm）；4mil（2-4.5mm） |
| Finished copper thickness 35-70um, | 5mil（＜2mm）；6mil（2-4.5mm） |
| Finished copper thickness >70um, | 7mil（＜2mm）；10mil（2-4.5mm） |
| Min the distance between NPTH edge to external conductor before compensation | 4oz 2 oz normal |
| Max finished external copper thickness | 8mil 5mil（Gold finger area） |
| The max board thickness for 0.15mm drill bit | 0.8mm |
| Min laser hole diameter | 0.1mm |
| Min finish half PTH via diameter | 0.3mm |
| Min NPTH tolerance | ±2mil(limit+0，-2mil or +2mil，-0) |
| Min space between via hole walls in different net, before compensation | 10mil(after compensation) 12mil (normal)(after compensation) |
| Tolerance of stiffener tape | ±0.1mm (Normal ±0.2mm) |
| Tolerance of Coverlay | ±2mil ((Normal ±4mil) |
| Min distance between coverlay opening and conduct | 3mil ((Normal 4mil) |
PCB manufacturing Capabilities
| Normal Tg FR4(Halogen free) | Shengyi S1150 |
| High Tg FR4(Halogen free) | Shengyi S1165 |
| HDI PCB material | LDPP（IT-180A 1037,1086）、Normal 106,1080 |
| High Tg FR4 | Isola：FR408、FR408HR、IS410、FR406、GETEK、PCL-370HR |
| Ceramic Particle Filled Laminates | Rogers：Rogers4350、Rogers4003;Arlon:25FR、25N; |
| PTFE Laminates | Rogers、Taconic、Arlon、Nelco、TP |
| PTFE PP | Taconic：TP、TPN、HT1.5(1.5mil)、Fastrise |
| Rigid PCB | Back board、HDI、 |
| Blind&buried via type | Laminating≤3 times |
| HDI PCB | 1+n+1、1+1+n+1+1、2+n+2、3+n+3 |
| Lead free | Flash gold、ENIG |
| aspect ratio | 10:01:00 |
| Max finished size | HAL Leaded 22"*39" |
| MIN finished size | HAL Leaded 5"*6" |
| PCB thickness | HAL Leaded0.6-4.0mm； |
| MAX high to gold finger | 1.5inch |
| Min space between gold fingers | 6mil |
| Min block space to gold fingers | 7.5mi |
| Max lamination cycle | 3 times |
| Min laser drill for stacked via | 0.1mm |
| Min stacked via pad size | 0.3mm |
| Max laser drilling size | 0.15mm |
| Blind Via Finished Hole Size | 0.3mm |
| Buried Via Finished Hole Size | 0.3mm |
| Non Conductive Filled Vias | 0.2mm~0.8mm |
| Conductive Filled Vias | 0.2~0.8mm |
| ENIG (Electroless Nickel/Immersion Gold) | AU： 0.05~0.1um Nickel: 3~5um |
| Hard gold | 0.1~1.0um |
| Soft gold | 0.1~1.0um |
| Lead Free HASL | 2~40um |
| Flash gold(electroplated gold) | Au 0.025-0.10um，Nickel 3~5um |
| electroplated Gold finger | Au 0.25-1.0um Nickel 3~5um |
| Selective Gold | Au 0.25-1.0um Nickel 3~5um |
| Tin Nickel | N/A |
| Immersion Silver | 0.2~0.4um |
| Soldermask | min. 8um, max. 30um |
| Min mechanical hole 4mil/6mil/8mi | 0.8mm/1.5mm/2.5mm |
| Finshed mechanical hole size | 0.1~6.0mm |
| MAX aspect ratio for Hole | 12:01:00 |
| Max aspect ratio for mechanical depth- control | 1.3:1 |
| Min. depth of Mechanical depth- control(backdrill) | 0.2mm |
| Min gap between hole wall conductor | 7mil |
| Min space between laser holes and conductor | 5mil |
| Min space bwteen hole walls in different net | 12mil |
| Min space bwteen hole walls in same net | 8mil |
| Min space bwteen NPTH hole walls | 10mil |
| Hole location tolerance | '+/-3mil |
| NPTH tolerance | '+/-0.05mm |
| Pressfit holes tolerance | '+/-0.05mm |
| Countersink depth tolerance | '+/-0.15mm |
| Countersink hole size tolerance | '+/-0.15mm |
| Min Pad size for laser drillings | 0.25mm |
| Min Pad size for mechanical drilling | 0.4mm |
| Min Pad size for mechanical drilling | 0.3mm |
| Min BGA pad size | 0.4mm |
| Pad size tolerance(BGA) | '+/-2mil |
| Min lead pitch | 0.3mm |
| Min BGA ball pitch | 0.3mm |
| Internal Layer | 1/3OZ: N/A |
| Internal Layer | 1/2OZ: 3.5/3.5mil |
| Internal Layer | 1OZ: 3/4mil |
| Internal Layer | 2OZ: 4/5mil |
| External Layer | 1/3OZ: 3/3mil |
| External Layer | 1/2OZ:3.5/3.5mil |
| Width tolerance | ≤10mil：+/-20% |
| Min copper pour to Pour | 7mil |
| Min copper pour to trace | 4mil |
| Min copper pour to microvia | 8mil |
| Min copper pour to buired via | 4mil |
| Min copper pour to SMD Pad | 5mil |
| Min copper pour to PTH Pad | 5mil |
| Soldermask color | Semi Gloss greeen\Gloss Green\Matte Green\Black\Red\Blue\Yellow |
| Solder Mask Min Dam Size | 4mil |
| Solder Mask Min Dam Size in BGA Area | 4mil |
| Solder Mask Registration | '+/-4mil |
| Silkscreen color | White, yellow , black |
| Min width of soldermask bridge | White, yellow , black |
| Min width of soldermask bridge | 4mil |
| Min. Diameter Rout Cutter Available | 0.6mm |
| Routed Part Size Tolerance | '+/-0.15mm |
| V-CUT symmetrical tolerance | '+/-0.1mm |
| MAX V-CUT lines | 80 lines |
| V-CUT angle tolerance | '+/-5 degress |
| V Score, Edge to Copper | H≤1.0mm:0.3mm(20°)、0.33mm(30°)、0.37mm(45°); |
| V Score, Edge to Copper | 1.0<H≤1.6mm:0.36mm(20°)、0.4mm(30°)、0.5mm(45°); |
| V Score, Edge to Copper | 1.6<H≤2.4mm:0.42mm(20°)、0.51mm(30°)、0.64mm(45°); |
| V-CUT angle | 20、30、45 degree |
| Gold finger bevelling | 20、30、45、60 degree |
| Gold finger bevelling tolerance | '+/-5 degree |
| Min space of gold finger chamfering | 6mm |
| Min gap between the side of | 8mil |
| Layer count | 1~28 layer |
| PCB thickness | 0.4~6..0mm |
| PCB thickness tolerance˄Normal | Thickness : ±10%(＞1.0mm)；±0.1mm(≤1.0mm)； |
| PCB thickness tolerance˄Special ˅ | Thickness ±0.1mm（≤2.0mm）；±0.15mm（2.1-3.0mm） |
| Min bow&twist | 0.75% |
| Controlled Impedance Tolerance | '+/-10% |
| Testing methods | Flying probe testing, Test fixture |
| Quality standards | IPC II, IPC III |
Testing Procedures
HDI PCBs are used in a variety of applications, including smartphones, tablets, laptops, and other portable electronic devices. They are also used in high-speed communication systems, military and aerospace systems, and medical devices.
- Smaller size: HDI PCBs can be made smaller than traditional PCBs due to their higher component density, making them ideal for use in compact electronic devices.
- Higher performance: HDI PCBs have a lower resistance and capacitance compared to traditional PCBs, which can result in improved performance and reliability.
- Increased flexibility: HDI PCBs can be designed with flexible or rigid-flex materials, allowing for greater design flexibility and the ability to fit into tight spaces.
- Improved heat dissipation: HDI PCBs can be designed with advanced thermal management techniques, such as the use of metal core materials, to improve heat dissipation and reliability.
- Higher reliability: HDI PCBs are less prone to failure due to their advanced manufacturing processes and materials, which can result in a longer lifespan and reduced maintenance costs.
- Customization options: HDI PCBs can be customized to meet the specific needs of different applications, including the use of specialized materials and high-density features such as blind and buried vias.
- Cost-effectiveness: While HDI PCBs may be more expensive upfront, their improved performance and reliability can make them more cost-effective in the long run, particularly in applications where traditional PCBs would not be able to meet the required specifications.
